Electrical parameters:

1.Frequency range: 1710-1880MHz 1850-1990MHz 1920-2170MHz

2.Polarization: ±45°

3.Gain:17.5±0.2dbi

4.Down-tilt:0-10°

5.Beam width: Horizontal 65°±2, vertical 7°

6.Upper side lobe restrain: ≥17dB

7.Cross polarization ratio: 15（@0°）、≥10（@±60）

8.Front-to-back ratio:>25dB

9.VSWR: ≤1.4

10.Isolation degree:>28dB

11.Third order intermodulation: <-107dBm

12.Input impedance: 50Ω

13.Power capacity: 200W

14.Anti-lightning protection: DC grounded

Basic mechanical performance:

1.Product category:4×7/16DIN female

2.Size (without package):1355*310*140mm

3.Size (with package):1600*340*230mm

4.Weight (without packet):14.2kg

5.Weight (with packet):22.5kg

6.Operating temperature: -40~+60℃

7.Mechanical down-tilt: 0~10°

8.Pole mounted: ￠50~￠115

9.Interface position: bottom

10.Antenna shield material: UPVC

11.Wind load area：0.4m2

12.Wind resistance: 60m/s

13.Limited temperature: -55~+75

14.Operating humidity: 8%~98%

Product feature:

FDD mode is able to transmit and receives on two separate, symmetry frequency channels. It uses the protected frequency band to separate transmission and receiving. FDD must adopt coupled frequencies, two symmetry frequency bands be used to realize transmission and receiving with the features of wide frequency band, fast transmission speed, high spectrum utilization and larger system capacity.
